Heaps & Priority Queues

Overview

A priority queue answers one question: what is the most important item right now? A binary heap is the standard way to implement it — a tree whose only ordering rule is that a parent outranks its children.

That rule is deliberately weaker than a BST's. A heap cannot tell you whether 42 is present, and cannot iterate in sorted order. It only knows its extreme, and in exchange it is cheap to maintain and needs no pointers at all.

Core Concepts

Term	Meaning
Heap property	Every parent ≥ its children (max-heap), or ≤ (min-heap)
Shape property	The tree is complete — every level full except the last, filled left to right
Sift up (bubble up)	Restore the property after inserting at the bottom
Sift down (heapify)	Restore the property after replacing the root
Priority queue	The interface; a heap is the usual implementation

Note what the heap property does not say: siblings are unordered, and a node deep in one subtree may be larger than a shallow node in another. Only the root is guaranteed to be the extreme.

Architecture / Mechanism

The array trick

The shape property means a heap has no holes, so it can live in a flat array with the tree structure implied by arithmetic — no left/right pointers, and perfect cache locality:

The same heap as a tree and as an array. Index 0 is the root; the children of index i sit at 2i+1 and 2i+2, and its parent at (i−1)//2. Wikimedia Commons, CC BY-SA 3.0

parent(i) = (i - 1) // 2
left(i)   = 2i + 1
right(i)  = 2i + 2

The two operations

Both work by moving one element along a single root-to-leaf path, which is why both are O(log n):

def push(heap, value):
    heap.append(value)                 # place at the end — keeps the shape
    i = len(heap) - 1
    while i > 0:                       # sift up while it outranks its parent
        parent = (i - 1) // 2
        if heap[parent] >= heap[i]:
            break
        heap[parent], heap[i] = heap[i], heap[parent]
        i = parent

def pop_max(heap):
    top = heap[0]
    heap[0] = heap[-1]                 # move the last element to the root
    heap.pop()
    i, n = 0, len(heap)
    while True:                        # sift down while a child outranks it
        largest = i
        for child in (2 * i + 1, 2 * i + 2):
            if child < n and heap[child] > heap[largest]:
                largest = child
        if largest == i:
            break
        heap[i], heap[largest] = heap[largest], heap[i]
        i = largest
    return top

Operation	Cost
Peek at the extreme	O(1)
Insert	O(log n)
Extract the extreme	O(log n)
Build a heap from n items	O(n) — not O(n log n)
Search for an arbitrary value	O(n)

Building a heap is linear, which is not obvious

Sifting down from every non-leaf node, working backwards from the middle of the array, costs O(n) rather than O(n log n). The reason is that most nodes are near the bottom and barely move: half the nodes are leaves and cost nothing, a quarter can sift at most one level, and so on. The sum Σ n/2^(k+1) · k converges to n. Use heapq.heapify(list) rather than pushing n times.

Practical Usage

import heapq

# Python's heapq is a MIN-heap operating in place on a plain list
heap = [5, 1, 8, 3]
heapq.heapify(heap)            # O(n)
heapq.heappush(heap, 2)        # O(log n)
smallest = heapq.heappop(heap) # O(log n)

# For a max-heap, negate — heapq has no key or reverse parameter
heapq.heappush(heap, -value)

# Pair (priority, item) tuples; add a counter to break ties so that
# unorderable items are never compared
import itertools
counter = itertools.count()
heapq.heappush(pq, (priority, next(counter), task))

# Top-k without sorting everything: O(n log k), not O(n log n)
top_10 = heapq.nlargest(10, huge_list)

Where priority queues show up:

• Dijkstra's algorithm — repeatedly take the nearest unvisited node. This is the single most important use.
• Heapsort — build a heap, then extract the maximum n times.
• OS scheduling — pick the highest-priority runnable task, as in process scheduling.
• Event simulation — process events in timestamp order as new ones are generated.
• Streaming top-k — keep a size-k min-heap; anything smaller than its root cannot make the cut. This uses O(k) memory regardless of stream length.
• Merging k sorted sequences — a heap over the k heads gives the next element in O(log k).

Edge Cases & Pitfalls

• heapq is a min-heap with no reverse= option. Negate values, or wrap them in a class with inverted comparison. Forgetting this is the most common heap bug in Python.
• Tuples compare element by element, so (priority, task) will compare task when priorities tie — and raise TypeError if tasks are not orderable. Insert a monotonic counter between them.
• You cannot efficiently change or remove an arbitrary element. Finding it is O(n). The standard workaround is lazy deletion: mark the entry invalid, push a replacement, and discard stale entries when they surface at the top.
• A heap is not sorted. Printing the backing array shows a valid heap that looks unsorted, because it is. Only repeated extraction produces order.
• heapq is not thread-safe. Use queue.PriorityQueue for concurrent access.

Comparisons

	Heap	Sorted array	Balanced BST
Peek extreme	O(1)	O(1)	O(log n)
Insert	O(log n)	O(n)	O(log n)
Extract extreme	O(log n)	O(1) at one end	O(log n)
Find arbitrary	O(n)	O(log n)	O(log n)
Sorted iteration	No	Yes	Yes
Memory overhead	None — a plain array	None	Two pointers per node

Use a heap when you only ever want the extreme; a balanced tree when you also need ordering or arbitrary lookup.

References

• Cormen, Leiserson, Rivest & Stein, Introduction to Algorithms, Ch. 6 — heaps, heapsort, and the O(n) build-heap analysis.
• CPython heapq source — the module's docstring is an unusually good explanation of the invariant.

Books & Videos

• Sedgewick & Wayne, Algorithms, 4th ed., §2.4 — "Priority Queues", with the heap developed from scratch.
