Character Encoding

Overview​

Text is stored as bits too — a character encoding is the mapping between abstract characters and the bytes that represent them. ASCII was the original, US-English-only 7-bit scheme; Unicode replaced it with a single universal set of characters, but Unicode itself doesn't say how to turn a character into bytes — that's the job of an encoding like UTF-8. Nearly every "weird symbols in my text" bug (mojibake) comes from mismatching which encoding was used to write bytes versus which encoding is used to read them back.

Core Concepts​

TermMeaning
ASCIIA 7-bit encoding for 128 characters (English letters, digits, punctuation, control codes).
Code pointA number assigned to an abstract character by the Unicode standard, written U+XXXX (e.g., U+0041 = A).
EncodingThe rule for turning code points into bytes (UTF-8, UTF-16, UTF-32 are all encodings of Unicode).
Code unitThe fixed-size chunk an encoding operates in (1 byte for UTF-8, 2 bytes for UTF-16).
MojibakeGarbled text produced by decoding bytes with the wrong encoding.
BOM (Byte Order Mark)An optional leading marker (U+FEFF) that signals encoding/endianness — mostly a UTF-16 concern.

Architecture / Mechanism: UTF-8​

UTF-8 encodes every Unicode code point (U+0000 to U+10FFFF) in 1 to 4 bytes, chosen so that ASCII bytes (0x00-0x7F) are completely unchanged — this is why UTF-8 is backward compatible with ASCII: any valid ASCII file is already valid UTF-8.

The table it stays compatible with is this one, unchanged since 1967:

The 7-bit ASCII table, listing control characters in the first two columns and printable characters — digits, uppercase letters, lowercase letters and punctuation — in the remaining columns
7-bit ASCII: 128 code points, of which the first 32 are control characters. Everything above 0x7F was left undefined — the gap that a hundred incompatible 8-bit code pages, and eventually Unicode, moved into. Wikimedia Commons, Public domain

Two pieces of deliberate design in that layout still pay off. Digits start at 0x30, so c - '0' converts a digit character to its value. And uppercase and lowercase differ by exactly one bit (0x20), which is why case conversion for ASCII is c | 0x20 and c & ~0x20 — a trick worth recognising in others' code, though never one to apply to non-ASCII text.

Code point rangeBytesBit pattern
U+0000–U+007F10xxxxxxx
U+0080–U+07FF2110xxxxx 10xxxxxx
U+0800–U+FFFF31110xxxx 10xxxxxx 10xxxxxx
U+10000–U+10FFFF411110xxx 10xxxxxx 10xxxxxx 10xxxxxx

The leading bits of the first byte tell a decoder exactly how many bytes follow — no need to scan from the start of the file to know where a character begins, and continuation bytes (10xxxxxx) are unambiguous:

Worked example: encoding é (U+00E9, decimal 233) falls in the U+0080-U+07FF range, so it needs 2 bytes:

233 in binary: 11101001  (8 bits)
Split into 5 + 6 bits to fit the template 110xxxxx 10xxxxxx:
  00011 101001
Result: 11000011 10101001  =  0xC3 0xA9

Practical Usage​

#include <string>
#include <iostream>

std::string s = "café"; // UTF-8 source, encoded by the compiler as bytes
std::cout << s.size() << "\n";       // 5 — 'é' takes 2 bytes in UTF-8, not 1 "character"

// Iterating byte-by-byte (std::string::size()/operator[]) is byte iteration,
// NOT code-point iteration. Use a Unicode-aware library (ICU, utf8cpp, std::u8string
// helpers) if you need to count "characters" correctly.

Edge Cases & Pitfalls​

.size()/.length() counts bytes (or UTF-16 code units), not "characters"

std::string::size() in C++ (UTF-8 assumed) counts bytes; .length on a JavaScript string counts UTF-16 code units. Both can disagree with the number of visible characters — especially for emoji, which are often outside the Basic Multilingual Plane and need 2 UTF-16 code units (a "surrogate pair") or 4 UTF-8 bytes.

Mojibake: decoding with the wrong encoding

Opening a UTF-8 file as if it were Latin-1 (ISO-8859-1) turns each multi-byte UTF-8 sequence into several garbled Latin-1 characters (the classic café → café bug). The fix is always to know and declare the encoding explicitly — HTTP Content-Type: charset=utf-8, an XML/HTML <meta charset> tag, or an explicit encoding parameter when opening a file — rather than guessing.

  • Not all byte sequences are valid UTF-8 (continuation bytes must follow the right lead byte) — malformed input must be explicitly handled (reject, replace with U+FFFD, etc.), not assumed away.
  • A leading UTF-8 BOM (EF BB BF) is legal but often unwanted — some tools/parsers choke on it because it's not itself a printable character.

Comparisons​

EncodingBytes per charASCII-compatibleTypical use
ASCII1 (7-bit)N/A — its own base caseLegacy, protocol control bytes
UTF-81-4, variableYes — identical for U+0000-U+007FWeb, files, most modern systems (default almost everywhere)
UTF-162 or 4 (surrogate pairs)NoWindows APIs, Java/JavaScript internal string storage
UTF-324, fixedNoSimplicity of one code point = one unit; rarely used for storage (space-inefficient)
