The Network Layer and Routing

Overview​

The network layer's job is addressing and forwarding across different networks — the piece that lets a packet leave your home LAN, cross however many intermediate networks, and arrive at a server on the other side of the world. On the Internet, this layer means the Internet Protocol (IP), in its IPv4 and (increasingly) IPv6 forms, plus the routers that forward packets hop by hop based on destination IP address.

Core Concepts​

TermMeaning
IP addressA numeric address identifying a network interface: 32 bits for IPv4, 128 bits for IPv6.
SubnetA logical subdivision of an IP network — a contiguous block of addresses that share a common prefix.
CIDR notationaddress/prefix-length (e.g., 192.168.1.0/24) — the modern way to express a subnet's size without a separate subnet mask.
Routing tableA list of (destination network → next hop) entries a router (or host) uses to decide where to forward a packet.
Default gatewayThe next hop a host sends a packet to when the destination isn't on its local subnet.
NAT (Network Address Translation)Rewriting source/destination addresses in transit, most commonly to let many private IPs share one public IP.

Architecture / Mechanism​

IPv4 Addressing​

An IPv4 address is 32 bits, written as four dotted decimal octets: 192.168.1.10. With only ~4.3 billion possible addresses and far more than that many devices on the Internet, IPv4 address exhaustion is the reason both NAT and IPv6 exist.

Those addresses are two fields of a twenty-byte header prepended to every packet:

The IPv4 header laid out as 32-bit rows: version, IHL, TOS and total length; identification, flags and fragment offset; TTL, protocol and header checksum; then source and destination addresses, optional options, and the data
The IPv4 header — 20 bytes without options. Source and destination take 8 of those bytes; the rest is the bookkeeping that makes forwarding, fragmentation and loop-prevention work. Wikimedia Commons, CC BY-SA 4.0

Three of those fields explain behaviour you will actually observe:

FieldWhy you notice it
TTLDecremented by every router; a packet hitting zero is dropped and an ICMP error returned. This is both the loop-killer and the mechanism traceroute exploits to discover each hop in turn.
ProtocolNames what the payload is (6 = TCP, 17 = UDP, 1 = ICMP) so the receiving host knows which handler to pass it to — the "up" step of decapsulation.
Flags / Fragment offsetSupport splitting an oversized packet across several frames. The Don't Fragment flag plus a too-small MTU somewhere on the path is the classic cause of connections that complete a handshake and then hang on the first large transfer.

IPv6 (Briefly)​

IPv6 uses 128-bit addresses, written as eight groups of hex digits (e.g., 2001:0db8:85a3:0000:0000:8a2e:0370:7334, often abbreviated 2001:db8:85a3::8a2e:370:7334). Its address space is large enough that NAT is no longer necessary for address conservation (though it's still sometimes used for other reasons). Global IPv6 adoption has grown steadily but IPv4 (usually behind NAT) still dominates most networks as of the mid-2020s.

Subnetting and CIDR​

A subnet mask (or CIDR prefix length) splits an IP address into a network portion and a host portion. /24 means the first 24 bits identify the network; the remaining 8 bits identify hosts within it.

Worked example: 192.168.1.0/24

192.168.1.0/24
├─ Network bits:  192.168.1   (24 bits — fixed for every host on this subnet)
├─ Host bits:     .0-.255     (8 bits → 256 addresses)
├─ Network address:    192.168.1.0    (all host bits = 0, not assignable to a device)
├─ Broadcast address:  192.168.1.255  (all host bits = 1, not assignable to a device)
└─ Usable host range:  192.168.1.1 – 192.168.1.254   (254 usable addresses)

If you instead needed only 4 usable addresses (say, a point-to-point link plus a couple of hosts), you'd use a smaller block like 192.168.1.0/30 (2 host bits → 4 addresses, 2 usable after network/broadcast are reserved) — CIDR lets you size a subnet to actual need instead of only ever handing out fixed class-based blocks (the old, now-obsolete Class A/B/C system).

What a Router Does​

A router receives a packet, strips the data-link framing, looks at the destination IP address, and consults its routing table to find the most specific matching route (longest prefix match). It then forwards the packet out the appropriate interface toward the next hop — repeating hop by hop until the packet reaches a router directly attached to the destination's subnet.

NAT​

Network Address Translation rewrites the source IP (and port) of outgoing packets from a private address (e.g., 192.168.1.10) to a router's single public IP, tracking the mapping so return traffic can be translated back. It exists primarily because IPv4's address space is far smaller than the number of devices that need to reach the Internet — an entire home or office network can share one public IPv4 address. A side effect is that NAT also hides internal topology and provides a mild, incidental security benefit (unsolicited inbound connections have no mapping to follow), though it is not a substitute for a firewall.

Practical Usage​

Tracing the route packets take, and inspecting local routing/addressing:

$ traceroute example.com
traceroute to example.com (93.184.216.34), 30 hops max, 60 byte packets
 1  192.168.1.1 (192.168.1.1)  1.203 ms  1.150 ms  1.102 ms
 2  10.20.0.1 (10.20.0.1)  8.421 ms  8.390 ms  8.355 ms
 3  203.0.113.1 (203.0.113.1)  12.004 ms  11.980 ms  11.955 ms
 ...
 9  93.184.216.34 (93.184.216.34)  84.221 ms  83.998 ms  84.150 ms

$ ip route
default via 192.168.1.1 dev eth0
192.168.1.0/24 dev eth0 proto kernel scope link src 192.168.1.10

Each traceroute line is one router hop — the first is almost always your default gateway. ip route shows the local routing table: anything on 192.168.1.0/24 is reached directly; everything else goes to the default route via the gateway at 192.168.1.1.

Edge Cases & Pitfalls​

Subnet math errors are a top cause of "can't reach this host" bugs

Getting the prefix length wrong (e.g., configuring /24 when you meant /25) silently splits or merges subnets in ways that cause some hosts to be unreachable directly and require routing through a gateway they weren't expecting to need. Always double check host count math: a /N prefix leaves 32 - N host bits, i.e. 2^(32-N) addresses, minus 2 for network/broadcast in most cases.

  • Private address ranges (10.0.0.0/8, 172.16.0.0/12, 192.168.0.0/16 per RFC 1918) are never routed on the public Internet — they only make sense behind NAT.
  • Double NAT (e.g., an ISP-provided modem/router and your own router both doing NAT) can break protocols that embed IP addresses in application data or require inbound connections, and often needs manual port-forwarding configuration on both devices.
  • IPv6 doesn't use broadcast at all (it uses multicast/anycast instead), which changes some assumptions carried over from IPv4-only thinking, including how ARP-equivalent neighbor discovery works.

Comparisons​

AspectIPv4IPv6
Address size32 bits (~4.3 billion addresses)128 bits (effectively unlimited for foreseeable use)
NotationDotted decimal (192.168.1.10)Colon-separated hex (2001:db8::1)
NATWidely used to cope with address scarcityNot required for address conservation
BroadcastSupportedRemoved in favor of multicast

References​

  • IETF, RFC 791 — Internet Protocol (IPv4).
  • IETF, RFC 8200 — Internet Protocol, Version 6 (IPv6) Specification.
  • IETF, RFC 4632 — Classless Inter-domain Routing (CIDR): The Internet Address Assignment and Aggregation Plan.
  • IETF, RFC 1918 — Address Allocation for Private Internets.

Books & Videos​

  • Kurose & Ross, Computer Networking: A Top-Down Approach — network-layer chapter covers routing algorithms and addressing in depth.
  • W. Richard Stevens, TCP/IP Illustrated, Volume 1 — deep, packet-level treatment of IP and routing.
